The NL-SW-LTE-TC4APG Skywire® APAC 4G LTE Cat 4 embedded modem is the fastest and most cost-effective way to bring cellular connectivity to your IoT products in Asia-Pacific. The CAT 4 APAC modem delivers exceptional download and upload speeds and has Fallback to 3G.

Skywire embedded modems dramatically reduce the cost, risks and timelines of IoT product development. With known-good RF engineering and fully validated software, Skywire allows you to focus on your application and not engineering cellular radios. Standardized connectivity gives you flexibility to update and alternate radios for new geographies, carriers and technologies. Further, our embedded modems are “End-Device Certified”, meaning your end-product will not need to go through the complex process of carrier certification. This is critical for the first release of your product and each iteration as you obtain market feedback. Skywire modems significantly reduce time-to-market and are ideal for product development through large-scale production. All Skywire modems are patented and backed by industry leading documentation and expert-level product support.


  • Skywire Form-Factor
  • 4G LTE Category 4 with 3G fallback
  • All RF Engineering contained within the modem
  • Carrier End-Device certified
  • U.FL port for flexible antenna options
  • Direct module access via Serial UART or USB
  • Multi-Carrier Support on a Single Device
  • Skywire family pin compatability
  • RoHS compliant
  • Development kits available


  • Longest Network Life
  • CAT 4 LTE Speeds (Up to 150 MB down/50 MB up)
  • Improved reception with RX diversity
  • Penta-Band LTE support
  • GPS, Glonass, Beidou, Galileo, QZSS
  • Bundled data plans available

Tech Specs

  • Throughput LTE: 150 Mbps Download/50 Mbps Upload  |  HSPA+: 42Mbps Download/5.76 Mbps Upload
  • Average: TBD
  • Peak: TBD
  • Idle: TBD
  • Sleep: TBD
  • Supply Voltage: 3.4V – 4.2V (3.8V Nominal)
  • Input Voltage: TBD
  • I/O Voltage: 1.65V-5.5V
  • Temperature Range: -40ºC to +85ºC
  • Dimensions: 29mm x 33mm x 10.5mm
  • Weight: 8 grams
  • RoHS Compliant
  • Bands
    • LTE CAT 4, 3GPP Release 10 Compliant (FDD B1[2100], B3[1800], B5[850], B8[900], B9[1800], B18[850], B19[850], B26[850], B28[700])
    • HSPA+ (B1[2100], B5[850], B6[800], B8 [900], B19[800])
  • Certifications: RoHS Certificate of Compliance
