The AirLink® RV50X is the industry’s lowest power and most rugged LTE gateway. Simple to install and easy to manage, the Semetch AirLink® RV50X industrial gateway is designed to connect critical assets and infrastructure. Ideal for industrial-grade applications in energy, utilities, and smart-city infrastructure, the Semtech AirLink® RV50X provides real-time remote connectivity for SCADA, distribution management systems, and metering. With the lowest power consumption available on the market, the AirLink® RV50X dramatically reduces infrastructure costs when running on battery or solar power, and provides programmability to enable edge computing applications, using the ALEOS Application Framework (AAF).
The Semtech AirLink® RV50X supports LTE Advanced capabilities, with an extensive range of LTE bands worldwide, delivering up to 300 Mbps downlink speeds.
- LTE-Advanced performance at 2G power consumption – Uses less than 1 watt
- Ideal for solar-powered applications
- Ruggedized, industrial-grade form factor
- Enables edge computing applications with ALEOS Application Framework (AAF)
- Remote, secure network management in the cloud or in the enterprise
- Network management and support with AirLink® Complete
Semtech AirLink® RV50X Benefits
Rugged Design for Demanding Environments
Designed to withstand harsh industrial conditions, is the AirLink® RV50X is capable of surviving 5 V brownouts and spikes from -600 VDC to 200 VDC. Certified as Class I Div 2, it is ideal for hazardous environments. The die-cast aluminum housing is sealed to meet IP64 for resistance to dust and water ingress.
The AirLink® RV50X is tested to meet and exceed the MIL-STD-810G specification for shock, vibration, temperature, and humidity. The built-in power supply protection makes it suitable for harsh electrical environments such as compressors, generators, and excavators.
Ultra-Low Power Consumption
The AirLink® RV50X offers best-in-class power consumption combined with LTE performance and is optimized for battery and solar applications. It is the industry’s only LTE gateway with 2G power consumption, operating at 900 mW in idle mode. For 3G deployments migrating to LTE, the RV50X will work with existing power infrastructure, eliminating the need to invest in replacement solar panels or batteries. Standby Mode provides additional protection for batteries by dropping power consumption to 53 mW, and can be triggered by timers, low voltage detection or I/O.
Ideal for global deployments, the RV50X provides worldwide LTE coverage with just two product variants; one for North America and EMEA, and one for Asia-Pacific.
With support for network operator switching—automatic configuration of the radio, based on the SIM—the RV50X provides versatility and simplicity when changing between network operators at any time.
